New Arrival - 1206 High Voltage SMD Fuse 250V

AMPFORT released new product - 1206 high voltage smd fuse up to 250V

High -voltage patch fuses are widely used, especially in electronic devices. Their main function is to quickly cut off the circuit when the circuit is abnormal current, thereby protecting the equipment from damage. The design and manufacturing process of this fuse needs to be accurately controlled to ensure that they can provide reliable protection in various environments.

First, the application of high -voltage patch fuses occupies an important position in the power management system. Among many electronic devices, such as mobile phones, computers, TVs, etc., the power management system is its core part. These devices need stable power supply to ensure their normal operation. However, for various reasons, such as voltage fluctuations, short circuit, overheating, etc., the power system may cause abnormalities. At this time, the high -voltage patch fuse will start, and quickly cut off the power to prevent further damage to the device.

Secondly, high -voltage patch fuses are also widely used in automotive electronic systems. A large number of electronic control systems, such as engine management systems, brake systems, navigation systems, etc. within modern vehicles. The stable operation of these systems is essential for the safety of the vehicle. However, similar to electronic devices, the automotive electronic system may also encounter a problem with the power system. In addition, cars may encounter various accidents during driving, such as short circuit and line failure. In these cases, high -voltage patch fuses can effectively protect the electronic system of the car and avoid vehicle failures caused by circuit problems.

Model	Current Rating	Voltage Rating	Interrupting Ratings ①	Nominal Cold DCR (Q) ②	Nominal I²t (A²s) ③
	(A)	(VDC)	/	（mΩ)	(W)
AT1206-0450	4.5	250	50A @ 250VDC 100A@125VDC 300A @ 32VDC	19.20	2.91
AT1206-0500	5	250		14.80	3.60
AT1206-0600	6	250		13.20	5.18
AT1206-0650	11	250		9.90	6.08
AT1206-1100	2.5	250	50A @ 125VDC 100A @ 65VDC 300A @ 32VDC	3.50	17.42
AT2410-0250	3	250	50A @ 250VDC 100A@125VDC 300A @ 32VDC	36.80	1.13
AT2410-0300	3	250		28.40	1.69
AT2410-0350	3.5	250		25.40	2.38
AT2410-0400	4	250		18.90	3.23
AT2410-0800	8	250	50A @ 125VDC 100A @ 65VDC 300A @ 32VDC	6.70	14.75

In addition, high -pressure patch fuses have been widely used in industrial equipment, medical equipment and other fields. For example, in industrial automation equipment, high -voltage patch fuses can protect motors and drivers from overloading and short circuit effects. In medical equipment, high -voltage patch fuses can protect the effects of sensitive electronic equipment from voltage fluctuations and electromagnetic interference.

In general, the application of high -voltage patch fuses not only protects the safety of electronic equipment, but also provides a guarantee for the stable operation of various equipment. With the continuous development of science and technology, the design and manufacturing technology of high -pressure patch fuses are also continuously improving, and it will be wider in future applications.
